Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting
Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting
Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting
Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting
Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting
Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting

loading

Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button

  • SNO-PL-B-FP

  • SNO-PL-B-FP

power:
40W±10%
Size:
595*595*27mm
Lumen:
4000lm±10%
Efficency:
100lm/w
Beam angle:
90°±10
CCT:
4000K/6500K Selectable
IP Grade:
IP 20
SKU:
Availability:
Inquiry

Product Name
Backlit Panel Lamp
Product Model
SNO-PL-B-FP-40W
Material
Al Frame + Iron Backpanel
Size
595*595*27mm
Input Mode
DC male and female cables
Installation Mode
Embedded
Voltage
220-240V
Frequency
50/60HZ
wattage
40W
Power Factor
PF>0.9
Start-up time
≤1S
THD
≤20%
Ripple Current
≤5%
Lumen
4000lm
Efficency
100lm/w
Beam Angle
90°
CCT
4000K
6500K
Ra
>80
R9
N/A
SDCM
＜6
Stroboscopic
Non-Flicker（＜5％）
UGR
＜19
Dimmer
Non-Dim
Lifetime requirements（L70/B50)
L70
Lifetime
50000hrs
Surge
1kV
Switch cycles
＞25000
Voltage Resistance （Vac）
3000
USE LOCATIONS
DAMP
IP Grade
IP20
Warranty
5 years

Made in China 40W LED White Backlight Panel Light 4000K/6500K Optional IP20 Indoor Lighting

1. Backlit panel lamp with aluminum frame and iron back panel 40W 5-year warranty 4000K 6500K IP20 indoor lighting can be selected
